Explore and download 20+ CAD Drawings of outdoor shades that are ideal for helping you create a sense of serenity in your outside spaces and protecting your home, restaurant, and more from the weather.

At GameTime, they enrich the lives of children and communities through play. Because as product engineers and parents, manufacturers and members of our home communities - They believe in play. Since 1929, they have brought meaningful research around the importance of play to the design, engineering, manufacture and delivery of play equipment. Their work has elevated industry standards on safety, physical and mental development, inclusion and intergenerational interaction. Uniting deep research with fun, information with inspiration, science with play.

Humboldt Sawmill is the leading supplier of Forest Stewardship Council ® (FSC ® C013133) certified redwood and Douglas-fir lumber products; logs are sourced from 440,000 acres of company-owned timberlands in California. An additional 400,000 acres are available under a long-term log purchase agreement. Products manufactured at company-owned mills include redwood decking, timbers, and uppers, as well as Douglas-fir joists and planks, and posts. and beams. All products available FSC certified at dealers and distributors throughout the Western U.S. and beyond.

Phantom Screens provides solar shading, insect protection, privacy, and climate control without compromising building aesthetics or people’s views of the outside. All of their solutions are retractable - which remain out of sight until needed and integrate seamlessly with the architecture. With their North America-wide professional installer network, they make it easy for design/build professionals to integrate retractable screens into their projects. Their teams can provide design consultation, onsite measuring, installation and aftermarket maintenance.

Just add shade: Maglin Site Furniture offers a variety of umbrella-accommodating tables. With a clean, contemporary style, Foro Collection tables can be configured in a variety of sizes, shapes, heights, surface patterns, and mounting options to suit your site’s needs. Tabletops come in patterned metal or HDPE with optional 2” umbrella hole. Inspired by Scandinavian design, Kontur Collection café tables, are simple yet refined, durable, and strong. Kontur café tables come standard with a 2” umbrella hole and feature a rolled edge and sturdy 3-leg design. Bring people together in public parks and on campuses with the 400 Series – 400 cluster seating unit. The frame is constructed using HS steel tube and flat bar, with tabletop and seats available in Ipe wood, metal, or HDPE. This traditional table and seating system can be customized to your site’s needs with wheelchair accessibility, a gaming board, and a 2” umbrella hole.

With over 100 years of industry experience, Academy is a leader in the custom manufacturing and installation of commercial awnings, canopies, umbrellas, shade structures, signs, and cabanas. Customers of their custom canopies and awnings include some of the premier names in the restaurant, hospitality, retail, and commercial development industries in every state and in over 15 countries – all of who have benefited from their commercial shade products. They are renowned as one of the leading awning companies in the U.S., transforming the look and feel of a business the moment they complete the job of installing awnings and canopies for entrances, display windows, and open-air events.

CABANAS

ICON Shelter Systems, Inc. designs, engineers and fabricates steel framed open structures for use in outdoor public spaces. The fastest growing shelter line in the industry consists of park shelters, gazebos, pavilions, arbors, colonnades, kiosks, transit shelters and clock towers in a variety of shapes, sizes and configurations. ICON is distinct in the industry for its offering of 1-foot increments on shelter sizing and pricing. Other companies may tack on high custom charges for making a shelter that falls between their standard sizes, usually given in 4-foot increments. All ICON shelters are priced relative to their sizes.

SHELTERS

Driven by an unmatched legacy of quality and service, their products are designed for the way you live. From welcoming the sunlight each morning to providing privacy and comfort each night, LEVOLOR Blinds, Shades, and Shutters make quality time last longer today, tomorrow, and every day. With a 100-year history of quality, they are the brand homeowners trust most. From the high caliber materials to the innovative technology built into each product, they consider every detail to create blinds, shades, and shutters that work the way they’re supposed to — every time. At LEVOLOR, they embrace their role as an industry leader and invest in meaningful innovations to improve your quality of life. From energy-efficient designs to motorized operations, they provide thoughtful solutions for every home. They rigorously test all LEVOLOR products to ensure they meet the highest quality standards. They are committed to delivering reliable products that stand the test of time and back each one up with a Limited Lifetime Warranty.

BLINDS & ROLLER SHADES

RCP Shelters is the industry's most diverse shelter manufacturer offering a variety of pre-engineered shade structures customizable to your preference and needs.

SHADE STRUCTURES

At ShadeScapes you will find the best selection of premium architectural and commercial-grade sunshades, including cantilever, offset, wall mount and market umbrellas, cabanas, shade sails, shade leafs, multi and giant umbrellas, and other sophisticated shade options.

UMBRELLAS

Interested in more CAD Drawings? Download CADdetails’ QuickPacks to instantly receive design files ready for use in your next project.
