Friday Feature - July 27th Edition

Friday Feature - July 27th Edition

In this edition we're showcasing 3D models by Tri-State Stone & Building Supply Inc., Universal Window & Door, Wausau Sliding System, & Williams Brothers Corporation of America. We've also gathered projects from Couturier Iron Craft, Brentwood Industries, The Cable Connection, and Eldorado Fireplace Surrounds.


3D Model Highlights

 View and download the 3D model  here .

View and download the 3D model here.

Tri-State Stone & Building Supply, Inc. - Garden Retaining Wall

Carderock® Garden Wall Stone - irregular in shape and somewhat flat, this grade of stone is ideal for dry of semi-dry stack retaining walls up to 24" in height, such as those defining a raised garden bed. With one reasonably good face, 8" to 12" deep, 3" to 6" in height, up to 18" in length, coverage of 18 to 20 square feet per ton can be expected.


Universal Window and Door - Series 700 Steel Replica

Historic Steel and Wood Replica Window

 View and download the 3D model  here  .

View and download the 3D model here.


 View and download the 3D model  here .

View and download the 3D model here.

Wausau Siding Systems - Trim with Nailing Fin

Accent the architecture and beauty by adding distinction to doors, windows and gables for the perfect finishing touch. All the warmth and beauty of wood. Designed with the installer in mind, enjoy the speed and simplicity of installation with our nail fin; homeowners can appreciate the cost savings in labor with quicker installation. Hidden fastener system eliminating blow outs, sunken or unsightly nails and bad touch-up. Available in 4" and 6" widths, and in 16' lengths.


Williams Brothers Corporation of America - Fire Rated Heavy Duty Premium Security Access Door

This heavy duty fire-rated door is made of 14 ga. steel and has the added benefit of rolled safety edges for operator protection. This door can be used in any wall location which must have a fire rating.

 View and download the 3D Model  here .

View and download the 3D Model here.


Project Highlights



Couturier Iron Craft - Joint Deployment Fleet Forces

 image © Couturier Iron Craft

image © Couturier Iron Craft

Joint Deployment Fleet Forces Command Center, Norfolk, VA. Open Riser Curved Staircase with Stainless Steel Mesh Infill Panels.

View the full project here.



Brentwood Industries, Inc. - Leinenkugel Tenth Street Brewery

 image ©  Brentwood Industries, Inc.

image ©  Brentwood Industries, Inc.

Having worked together on previous projects, SDEI knew they could count on Brentwood for assistance with developing a stormwater management system that would both fit within site constraints and meet the necessary storage requirements. The two companies collaborated to draft initial system design options for conceptual planning and quotations.

View more project details here.



The Cable Connection - Piney River Ranch Railing

 image © The Cable Connection

image © The Cable Connection

The Cable Connection’s Ultra-tec® cable railing infill was used on this project. The installation was completed at Piney River Ranch which is outside of Vail, Colorado.

View the project here.

Eldorado Fireplace Surrounds - North Woods Cabin

 image © Eldorado Fireplace Surrounds

image © Eldorado Fireplace Surrounds

“There hasn’t been one person who has come to our home who didn’t think the stone was real. It’s a tribute to the authentic look and feel of Eldorado and we absolutely love it!” says Jones.

View the full project here.
